Container Types

List of some container types used by our carriers. You can view the details of the measures, flow and volume.

Tab Size Type Image Class Description ISO Code

lens
Size: 20
Type: BH
Class: BOX HARDTOP
Description: Dry Freight Container
Iso Code: 22U6
Inside Len MM: 5886
Inside Wid MM: 2342
Inside Hei MM: 2388
Inside Len Ft: 0
Inside Wid Ft: 0
Inside Hei Ft: 0
Door Wid mm: 0
Door Hei mm: 0
Weight Max Kg: 30480
Weight Max Lbs: 0
Weight Tare Kg: 2700
Weight Tare Lbs: 0
Weight Payd Load Kg: 27780
Weight Payd Load Lbs: 0
Capacity Cbm: 33
Capacity Ft: 0
20 BH hardtop container 20 sm BOX HARDTOP Dry Freight Container 22U6
lens
Size: 20
Type: BX
Class: BOX
Description: Dry Freight Container
Iso Code: 22G0
Inside Len MM: 5895
Inside Wid MM: 2350
Inside Hei MM: 2392
Inside Len Ft: 0
Inside Wid Ft: 0
Inside Hei Ft: 0
Door Wid mm: 2340
Door Hei mm: 2292
Weight Max Kg: 30480
Weight Max Lbs: 0
Weight Tare Kg: 2250
Weight Tare Lbs: 0
Weight Payd Load Kg: 28230
Weight Payd Load Lbs: 0
Capacity Cbm: 33
Capacity Ft: 0
20 BX general purpose container 20 sm BOX Dry Freight Container 22G0
lens
Size: 20
Type: FR
Class: FLAT RACK
Description: Flat/Platform
Iso Code: 22P8
Inside Len MM: 5662
Inside Wid MM: 2438
Inside Hei MM: 2327
Inside Len Ft: 0
Inside Wid Ft 0
Inside Hei Ft: 0
Door Wid mm: 0
Door Hei mm: 0
Weight Max Kg: 0
Weight Max Lbs: 0
Weight Tare Kg: 2530
Weight Tare Lbs: 0
Weight Payd Load Kg: 21470
Weight Payd Load Lbs: 0
Capacity Cbm: 0
Capacity Ft: 0
20 FR flat all types 20 sm FLAT RACK Flat/Platform 22P8
lens
Size: 20
Type: OT
Class: OPEN TOP
Description: Dry Freight Container
Iso Code: 22U1
Inside Len MM: 5888
Inside Wid MM: 2345
Inside Hei MM: 2365
Inside Len Ft: 0
Inside Wid Ft: 0
Inside Hei Ft: 0
Door Wid mm: 0
Door Hei mm: 0
Weight Max Kg: 30480
Weight Max Lbs: 0
Weight Tare Kg: 2250
Weight Tare Lbs: 0
Weight Payd Load Kg: 28230
Weight Payd Load Lbs: 0
Capacity Cbm: 32
Capacity Ft: 0
20 OT  open top container 20 sm OPEN TOP Dry Freight Container 22U1
lens
Size: 20
Type: RF
Class: REFRIGERATED CONTAINER
Description: Temperature Controlled Container
Iso Code: 22R1
Inside Len MM: 5428
Inside Wid MM: 2266
Inside Hei MM: 2240
Inside Len Ft: 0
Inside Wid Ft: 0
Inside Hei Ft: 0
Door Wid mm: 2286
Door Hei mm: 2188
Weight Max Kg: 30480
Weight Max Lbs: 0
Weight Tare Kg: 2940
Weight Tare Lbs: 0
Weight Payd Load Kg: 24060
Weight Payd Load Lbs: 0
Capacity Cbm: 28
Capacity Ft: 0
20 RF refrigerated temperature container 20 REFRIGERATED CONTAINER Temperature Controlled Container 22R1
lens
Size: 20
Type: VC
Class: VENTILATED CONTAINER
Description:
Iso Code: 22V0
Inside Len MM: 5888
Inside Wid MM: 2325
Inside Hei MM: 2392
Inside Len Ft: 0
Inside Wid Ft: 0
Inside Hei Ft: 0
Door Wid mm: 2334
Door Hei mm: 2290
Weight Max Kg: 30480
Weight Max Lbs: 0
Weight Tare Kg: 2400
Weight Tare Lbs: 0
Weight Payd Load Kg: 28080
Weight Payd Load Lbs: 0
Capacity Cbm: 33
Capacity Ft: 0
20 VC ventilated container 20 sm VENTILATED CONTAINER 22V0
lens
Size: 40
Type: BH
Class: BOX HARDTOP
Description: Dry Freight Container
Iso Code: 42U6
Inside Len MM: 12020
Inside Wid MM: 2342
Inside Hei MM: 2388
Inside Len Ft: 0
Inside Wid Ft: 0
Inside Hei Ft: 0
Door Wid mm: 0
Door Hei mm: 0
Weight Max Kg: 30480
Weight Max Lbs: 0
Weight Tare Kg: 4700
Weight Tare Lbs: 0
Weight Payd Load Kg: 25780
Weight Payd Load Lbs: 0
Capacity Cbm: 67
Capacity Ft: 0
40 BH hardtop container 40 BOX HARDTOP Dry Freight Container 42U6
lens
Size: 40
Type: BX
Class: BOX
Description: Dry Freight Container
Iso Code: 42G0
Inside Len MM: 12029
Inside Wid MM: 2342
Inside Hei MM: 2388
Inside Len Ft: 0
Inside Wid Ft: 0
Inside Hei Ft: 0
Door Wid mm: 2340
Door Hei mm: 2292
Weight Max Kg: 30480
Weight Max Lbs: 0
Weight Tare Kg: 3780
Weight Tare Lbs: 0
Weight Payd Load Kg: 26700
Weight Payd Load Lbs: 0
Capacity Cbm: 68
Capacity Ft: 0
40 BX general purpose container 40 sm BOX Dry Freight Container 42G0
lens
Size: 40
Type: FC
Class: COLLAPSIBLE FLAT RACK
Description: Flat/Platform
Iso Code: 42P8
Inside Len MM: 12080
Inside Wid MM: 2126
Inside Hei MM: 2043
Inside Len Ft: 0
Inside Wid Ft: 0
Inside Hei Ft: 0
Door Wid mm: 0
Door Hei mm: 0
Weight Max Kg: 0
Weight Max Lbs: 0
Weight Tare Kg: 5800
Weight Tare Lbs: 0
Weight Payd Load Kg: 29200
Weight Payd Load Lbs: 0
Capacity Cbm: 0
Capacity Ft: 0
40 FC  flat collapsible convertible platform 20 sm COLLAPSIBLE FLAT RACK Flat/Platform 42P8
lens
Size: 40
Type: FR
Class: FLAT RACK
Description: Flat/Platform
Iso Code: 42P8
Inside Len MM: 12080
Inside Wid MM: 2438
Inside Hei MM: 2103
Inside Len Ft: 0
Inside Wid Ft: 0
Inside Hei Ft: 0
Door Wid mm: 0
Door Hei mm: 0
Weight Max Kg: 0
Weight Max Lbs: 0
Weight Tare Kg: 5480
Weight Tare Lbs: 0
Weight Payd Load Kg: 25000
Weight Payd Load Lbs: 0
Capacity Cbm: 0
Capacity Ft: 0
40 FR high cube flat 40 sm FLAT RACK Flat/Platform 42P8
lens
Size: 40
Type: HC
Class: BOX HIGH CUBE
Description: High Cube Dry Container
Iso Code: 45G0
Inside Len MM: 12024
Inside Wid MM: 2350
Inside Hei MM: 2697
Inside Len Ft: 0
Inside Wid Ft: 0
Inside Hei Ft: 0
Door Wid mm: 2340
Door Hei mm: 2597
Weight Max Kg: 30480
Weight Max Lbs: 0
Weight Tare Kg: 4020
Weight Tare Lbs: 0
Weight Payd Load Kg: 26460
Weight Payd Load Lbs: 0
Capacity Cbm: 76
Capacity Ft: 0
40 HC high cube general purpose 40 sm BOX HIGH CUBE High Cube Dry Container 45G0
lens
Size: 40
Type: HH
Class: BOX HIGH CUBE HARDTOP
Description: High Cube Dry Container
Iso Code: 45U6
Inside Len MM: 12020
Inside Wid MM: 2342
Inside Hei MM: 2693
Inside Len Ft: 0
Inside Wid Ft: 0
Inside Hei Ft: 0
Door Wid mm: 0
Door Hei mm: 0
Weight Max Kg: 30480
Weight Max Lbs: 0
Weight Tare Kg: 4900
Weight Tare Lbs: 0
Weight Payd Load Kg: 25580
Weight Payd Load Lbs: 0
Capacity Cbm: 76
Capacity Ft: 0
40 HH high cube hardtop container 40 sm BOX HIGH CUBE HARDTOP High Cube Dry Container 45U6
lens
Size: 40
Type: OT
Class: OPEN TOP
Description: Dry Freight Container
Iso Code: 42U1
Inside Len MM: 12029
Inside Wid MM: 2342
Inside Hei MM: 2376
Inside Len Ft: 0
Inside Wid Ft: 0
Inside Hei Ft: 0
Door Wid mm: 0
Door Hei mm: 0
Weight Max Kg: 30480
Weight Max Lbs: 0
Weight Tare Kg: 3810
Weight Tare Lbs: 0
Weight Payd Load Kg: 26670
Weight Payd Load Lbs: 0
Capacity Cbm: 66
Capacity Ft: 0
40 OT open top container 40 sm OPEN TOP Dry Freight Container 42U1
lens
Size: 40
Type: RF
Class: REFRIGERATED CONTAINER
Description: Temperature Controlled Container
Iso Code: 42R1
Inside Len MM: 11207
Inside Wid MM: 2246
Inside Hei MM: 2183
Inside Len Ft: 0
Inside Wid Ft: 0
Inside Hei Ft: 0
Door Wid mm: 2216
Door Hei mm: 2128
Weight Max Kg: 0
Weight Max Lbs: 0
Weight Tare Kg: 4860
Weight Tare Lbs: 0
Weight Payd Load Kg: 25640
Weight Payd Load Lbs: 0
Capacity Cbm: 55
Capacity Ft: 0
40 RF refrigerated temperature container 20 REFRIGERATED CONTAINER Temperature Controlled Container 42R1
lens
Size: 40
Type: RH
Class: REFRIGERATED CONTAINER HIHT CUBE
Description: Temperature Controlled Container
Iso Code: 45R1
Inside Len MM: 11628
Inside Wid MM: 2294
Inside Hei MM: 2509
Inside Len Ft: 0
Inside Wid Ft: 0
Inside Hei Ft: 0
Door Wid mm: 2290
Door Hei mm: 2535
Weight Max Kg: 0
Weight Max Lbs: 0
Weight Tare Kg: 4430
Weight Tare Lbs: 0
Weight Payd Load Kg: 28070
Weight Payd Load Lbs: 0
Capacity Cbm: 67
Capacity Ft: 0
40 RH refrigerated temperature container 40 sm REFRIGERATED CONTAINER HIGH CUBE Temperature Controlled Container 45R1
